PE95420
UltraCMOS
®
SPDT RF Switch
The PE95420 is an RF SPDT switch and is available in a hermetically sealed ceramic package. The PE95420 is designed to cover a broad range of applications from 1 to 8500 MHz for use in various
Hi-Rel industries and applications requiring broadband performance. It uses Peregrine’s UltraCMOS®process and features HaRP™ technology enhancements to deliver high linearity and excellent harmonics performance. HaRP technology provides upgraded linearity performance. The PE95420 is an absorptive/non-reflective switch design, an excellent termination method for RF elements in a system design. A single-pin 2.2V CMOS logic control in a single chip solution reduces the number of control lines. It is offered in a small 7-lead CQFP and as DIE.
Title
Description
Download
Datasheet
PE95420 datasheet
