​RF Switches

Teledyne e2v Hi-Rel RF switches feature high linearity, isolation and exceptionally rugged performance for space applications.

 What's New?

​MILPITAS, CA – December 14th, 2021 – Teledyne e2v HiRel announces the availability of a rad-tolerant 20 GHz, Single Pole Double Throw (SPDT) absorptive RF switch, model TDSW020A2T, that is ideal for use in demanding high reliability, space and defense applications and is now available with qualified material off-the-shelf. This new RF switch, developed on 0.15 μm InGaAs pHEMT technology, will be available as die and is qualified per MIL-PRF-38534 Class K-equivalent​ for space applications.

Download the TDSW020A2T
Datasheet

​MILPITAS, CA – June 29th, 2021 – Teledyne e2v HiRel today announced availability of a new single-pole, double-throw multi-chip module (MCM) switch with world class power handling. The surface mount PIN-diode hybrid exhibits superior RF and thermal performance compared to MMIC​​ or glass carrier-based technologies.

Download the TDSW002040X
Datasheet




Products

PE95421
​SPDT
[A]
​1 8.5 ​0.77 ​1.38 ​38.0 75.6 33.0 60
​7L
CQFP
Space

PE95420
​SPDT
[A]
​1 8.5 ​0.77 ​1.38 ​38.0 75.6 33.0 60
​7L
CQFP
Space

PE9354
​SPDT
[R]
​10 3 ​0.55 ​0.55 ​32.0 32 31.0 -
​8L
CFP
Space


TDSW0602T


​SPDT
[R]
​.009 8.5 ​0.9 ​3.8 ​29 80
See
Fig.2 in
datasheet
48
Flip
Chip
Die
Military


TDSW002040X
​SPDT
[R]
​100 8.5 ​0.8 ​1 ​43 47 N/A 65
​2P
QFN
Military*


NEW
TDSW020A2T



​SPDT
[A]
​dc
20
​-
​3
​40
-
28.0
-
Wire-Bond Die
Space

* Available to US Markets only.

A=Absorbative | R=Reflective​
