REYNOLDS



PeeWee Series ​​•12 k​VD​C​ 2-pin

Altitude Rating
70,000 ft (21.34 km)

Operating Temperature
-55º to 125ºC

Current Rating
5 Amps

The PeeWee Series is another of Teledyne Reynolds' family of subminiature, high voltage connectors for use in applications where dense electronic packaging is required. Enabled by Teledyne Reynolds' patented Advanced Interface Sealing SystemTM; this unique method of sealing the high voltage interface at reduced atmospheric pressure to enable the series to be rated at 12 kVDC at 70,000 ft with a temperature range of -55° to 125°C.
