​​​Series​​​  ​Description




SHCDC​​
The SHCDC is a DC output Industrial Solid-State Relay ideal for applications where fast switching response times are critical. It is well-suited for applications requiring a high number of switching cycles, as its lifetime is not affected by frequent switching. It can be mounted on a panel or heatsink and is controlled by a DC voltage ranging from 4 to 32 V and includes an LED status output to indicate the presence of control voltage on the SSR.

Available options include:
SHC50DC10  DC Output: 10A, 1-500VDC / Control: 4.5-32 VDC / IP20 protection cove​r​
SHC20DC20​  DC Output: 20A, 1-200VDC / Control: 4.5-32 VDC / IP20 protection cover​
SHC20DC50​  DC Output: 50A, 1-200VDC / Control: 4.5-32 VDC / IP20 protection cover​​
SHC06DC50  DC Output: 50A, 1-60VDC / Control: 4-32 VDC / IP20 protection cover​
SHC06DC100 DC Output: 100A, 1-60VDC / Control: 4-32 VDC / IP20 protection cover


S20DC30
  ​
​Series S20 relays switch medium- to high-power DC loads. These devices feature the latest-generation MOSFET technology as well as an innovative isolated driver to ensure fast power turn on and off. The relays feature triggered control input to avoid linear control risks and fast switching times. The relays also offer an LED for status.​


Available options include:
S20DC30     30A, 0-130 Vdc Load; 4.5-32 Vdc Control


S20DC100
Series S20 relays switch medium- to high-power DC loads. These devices feature the latest-generation MOSFET technology as well as an innovative isolated driver to ensure fast power turn on and off. The relays feature triggered control input to avoid linear control risks and fast switching times. The relays also offer an LED for status.​​

Available options include:
S20DC100      100A, 0-130 Vdc Load; 4.5-32 Vdc Control​​​​


Series S60 relays switch medium- to high-power DC loads. These devices feature the latest-generation MOSFET technology as well as an innovative isolated driver to ensure fast power turn on and off. The relays feature triggered control input to avoid linear control risks and fast switching times. The relays also offer an LED for status.​




Available options include:
S60DC40      40A, 0-350 Vdc Load; 4.5-32 Vdc Control


S75DC150
Series S75 relays switch medium- to high-power DC loads. These devices feature the latest-generation MOSFET technology as well as an innovative isolated driver to ensure fast power turn on and off. The relays feature triggered control input to avoid linear control risks and fast switching times. The relays also offer an LED for status.​

Available options include:
S75DC150     150A, 0-42 Vdc Load; 4.5-32 Vdc Control​



SHDC
Series SH relays offer high performance in a fl​exible, innovative package. They feature the latest-generation MOSFET technology as well as triggered control input to avoid linear control risks. The relays offer diagnostics, removable touch-proof terminal covers and a metal base plate. They are up to 30% lighter than standard relays.​

Available options include:
SH10DC40           40A, 100 Vdc, 3.5-32 Vdc Control​
SH10DC40-16     40A, 60 Vdc, 3.5-32 Vdc Control​



 ​
 SI
Series SI relays are designed to switch high voltage (high power) DC loads. These devices feature the latest generation of High Voltage IGBT Technology as well as an innovative isolated driver to ensure fast power turn on and OFF. The relays feature triggered control input to avoid linear control risks and fast switching times. The relays also offer an LED for status.

Available options include:
SI60DC100     100A, 0-500 Vdc Load; 4.5-32 Vdc Control​





LS10​
Series LS10 DC solid-state relays are designed for mounting on printed circuit boards. They facilitate heat-sinking by providing an interface surface. They can switch loads with high starting currents. The nominal switched currents depend on the size of the heat sink These relays use a direct-bonded copper substrate for thermal efficiency and long life.

Available options include:
LS60DC10C-21    10A, 7-36 Vdc Load; 3-10 Vdc Control​
LS60DC10F-21    10A, 7-36 Vdc Load; 7-30 Vdc Control​
​​
 DX
​​Series DX relays are designed for DIN-rail mounting. These solid-state relays include a control LED that provides visual control status. Its compact size and user-friendly package make the Series DX relay an excellent choice for designers. The DX series relays offers long life versus mechanical relays.

Available options include:
DX6R3E-02     3A, 2-60Vdc Load; 3-30Vdc​ Control
DX6R3U-02    3A, 2-60Vdc Load; 90-240Vac/Vdc​ Control



 DS
Series DS single inline package (SIP) four-pin relays are designed for mounting on printed circuit boards. The relays are designed for medium-power DC loads. The Series DS relay is an alternative to electromechanical and reed relays. The DS series relays offers a long life versus mechanical relays.

Available options include:

​DS6R3E    3A, 2-60 Vdc Load; 3-30 Vdc Control​




​​​​​
