HIGH PERFORMANCE VCO - OA2CP12001
VCO model OA2CP12001 operates from 8000 to 12000 MHz and combines oscillator circuit, voltage regulator, MMIC amplifier, and bandpass filter in a two-stage CougarPak™ housing. Typical performance includes post tuning drift of ±3.0 MHz at 1 msecs relative to frequency at 1 second, 2:1 tuning linearity over frequency, and suppresses harmonics to better than –20 dBc. Output power is 10 dBm minimum over the –54°C to 85°C temperature range, covers the frequency range in 0 to –12 volts, and draws 250 mA from a 15 VDC supply.
Teledyne's line of high performance VCOs are suitable for challenging signal processing applications: aerospace, military, and industrial.
