OhmegaPly®

For many years Teledyne Labtech has manufactured RF & Microwave PCB with integrated OhmegaPly® resistors. OhmegaPly® is a thin film resistor-conductor material. Using standard subtractive printed circuit technology, integral resistors are formed on circuit layers. These resistors can be buried within a multilayer circuit board or used on the board surface. The resistors can also be used mounted on Metalbacked PCB.

OhmegaPly® is available in 25 ohm per square, 50 ohm per square and 100 ohm per square sheet resistivity.

  • High density interconnect
  • Ideal for power dividers
  • Large RF distribution boards
  • No access required for soldering SMD components



www.ohmega.com

OhmegaPly® is a registered trademark of Ohmega Technologies, Inc. Culver City, CA.
