This custom oscillator subassembly consists of two low noise oscillators covering 1.5 to 2.5 GHz, a power combiner, a standard Teledyne RF & Microwave amplifier, and a lowpass microstrip filter. Teledyne designed both oscillators for low phase noise and linear tuning. The output frequency bands are switched using standard TTL control.

​10 KhZ​-86
​100 KhZ​-114
​1 mHZ​-135
​10 mHZ​-150
​100 mHZ​-160
  • Frequency Output 1500 to 2500 MHz in Two Bands
  • +3 to +8 dBm Output Power
  • < 2 dB Output Power Flatness
  • Excellent Phase Noise
