Covering a broad frequency range of 24-40 GHz, Teledyne RF & Microwave's 3U VPX Downconverter is ideally suited for airborne, shipboard and radar applications.  This ruggedized unit offers excellent phase noise in a compact form factor.  It offers long operational life and enhanced interoperability using a flexible open systems compliant architecture.

High Dynamic Range

  • RF Coverage: 24-40 GHz, 16 GHz IBW
  • Noise Figure: 9 dB typical
  • Phase Noise: 1 MHz @-120 dBc/Hz
  • Linear Dynamic Range: 90 dB (with 1 MHz BW)

Built-in LO Generation

  • Single-tone, internally generated spurious:
    -80 dBc (@-15 dBm input and max gain)
  • Reference Frequency Input: 100 MHz


  • <500 g rugged air-cooled
