    ISOLATORS & CIRCULATORS At-A-Glance
  • FREQUENCY: 500 MHz to 26.5 GHz
  • BANDWIDTH: <1% to Multi-Octave
  • TECHNOLOGY: Ferrite Configuration 3 Port & 4 Port
  • PACKAGING: Connectorized Platforms Ground, Airborne, Marine
  • INTEGRATION WITH OTHER PRODUCTS: LNA's, Amplifiers, BAW Devices
  • EXPORT CLASSIFICATION: EAR99 & ITAR
A manufacturer of isolators and circulators for over 40 years, Teledyne RF & Microwave maintains a broad portfolio of broad-band and high power isolators and circulators with full MIL-Spec performance capabilities. With extensive experience in producing standard as well as customized solutions for the most demanding specifications, Teledyne performs product modifications to support both wide-band and narrow-band requirements.

MARKETS & APPLICATIONS


Teledyne Ferrite Isolators and Circulators have been utilized on Ground, Airborne and Marine platforms. End use applications:

  • Military
  • EW, Missile Radar
  • Communications
  • Test and Measurement
  • Commercial

KEY FEATURES



  • Circulators: 400 W peak, 28 watts average power
  • Isolators: 2 watts average reverse power w/ standard termination
  • Single and multiple junction designs
  • Covers standard bands and straddles octave bands, octave plus bands and commonly used narrow bands
  • Full MIL-Spec performance
  • Standard models meet shock and vibration per MIL-E-5400, Class II
  • Heat sink/cooling platform recommended for high power operation

​​








​​
