Teledyne RF & Microwave offers a range of Limiting Amplifiers which are used in instantaneous frequency and phase measurement receivers. The most important performance requirement of a limiting amplifier is to minimize output power variations, and provide a constant output over a wide input dynamic range.

  LIMITING AMPLIFIERS At-A-Glance
  • FREQUENCY: 10MHz to 35GHz
  • BANDWIDTHS: Narrow Band to Multi Octave
  • CONFIGURATION/PACKAGING: SM, Leaded, Connectorized, Waveguide
  • PLATFORMS: Ground, Airborne, Marine, Space
  • APPLICATIONS: Military, Commercial, Satcom, Comms
  • EXPORT CLASSIFICATIONS: EAR99 & ITAR

Teledyne Limiters and Limiting Amplifiers are available in Thru hole, Surface Mount or SMA package types, providing input protect limiting, fixed output limiting, and/or added Gain. Benefits include low VSWR and excellent Flatness vs. Frequency.

 TYPICAL SPECIFICATIONS

Limiting Amp
Model No.

Frequency Range (MHz)

P1dB

NF

Gain

LA507

50 – 500

12

6.5

13

LA1017

10 – 1000

13.5

6.7

12.5







Limiter
Model No.

Frequency Range (MHz)

Insertion Loss (dB, Typ.)

Max. Limiting (Typ.) 15V

LC1501

50 - 1500

2.7

+1.0

LC3005

10 – 1000

0.6

+1.0

LS6001

1000–6000

2.5

+2.5



 APPLICATIONS

  • Input protect limiting
  • Signal limiting
  • Communications
  • LO stability










​​
