GAIN SHAPE LINEARIZER AMPLIFIERS At A Glance
  • FREQUENCY: 10MHz to 35GHz
  • BANDWIDTHS: Narrow Band to Multi Octave
  • GAIN SHAPES: Linear, Parabolic and Custom
  • POWER: 1W to 10KW
  • CONFIGURATION/PACKAGING: Connectorized
  • PLATFORMS: Ground, Airborne, Marine, Space
  • APPLICATIONS: Military, Commercial, Satcom, Comms, TWTA
  • EXPORT CLASSIFICATIONS: EAR99 & ITAR

Gain Shape amplifiers are used in a number of applications where it's necessary to flatten the gain characteristic of the preceding or following component. This would include flattening the attenuation of a long cable run or perhaps changing the input gain response to an MPM (Microwave Power Module) or TWT (Traveling Wave Tube) to compensate for the gain variation within the tube.

 MARKETS & APPLICATIONS

Teledyne Linearizers have been utilized on Ground, Airborne, Marine, and Space platforms. End use applications:

  • Military
  • Communications
  • Commercial
  • Satcom
  • TWTA

 KEY FEATURES

One unique service Teledyne RF & Microwave offers is the ability to individually match a gain characteristic to a given tube's performance. This is done using Automatic Test Equipment (ATE) to calculate the gain needed at any particular frequency in order to maintain an overall flatness across the whole operating band. This is done without the need for the tube to be provided to Teledyne; all we need is the gain characteristics of the individual tube. Many gain shapes are available to compensate for many different interactions with gain.










​​
