Traveling wave tubes remain the best source for efficient generation of microwave power over broad frequency bandwidths.

Model Frequency (GHz) Peak Power (W) Duty (%) Max. Typical Gain (dB) Min/Max
@ Rated Pout
Efficiency (%) Typical Modulation
(Control Electrode)
Output Connection Weight (lbs/kg) (NTE)
MEC 3102 2.0 - 4.0 4,500 6 35 29 GRID SC 15.0/6.8
MTG 3041L2 2.0 - 8.0 2,000 6 38/58 24 GRID SC 8.0/3.6
MEC 3132 2.0 - 8.0 1000 6 40/48 17* GRID TNC 8.0/3.6
MTG 3041K 2.5 - 8.0 2,000* 6 43/68 21* GRID SC 8.0/3.6
MEC 3082B 2.7 – 4.0 10,000 4 41/47 33* GRID SC 15.0/6.8
MEC 3090X 2.8 - 3.6 13000 2 38/41 27 GRID N 30.0/13.6
MEC 3103 4.0 - 8.0 4,500 6 32/34 34 GRID WRD 350 15.0/6.8
MEC 3096 5.0 - 11.0 1,780 5 37/38 34 GRID WRD 475 9.0/4.1
MEC 3094A 5.35 - 5.65 8,000 4 46 33 GRID SC 8.0/3.6
MEC 3119 6.0 - 8.0 7000 4 41/43 33 GRID WRD 350 15.0/6.8
MTI 3444L 6.5 - 18.0 1,580* 6 43/46 14* GRID WRD 650/750 7.0/3.2
MEC 3848 8.0 - 11.0 8,000* 5 48/51 40 GRID WR 90 10.0/4.5
MEC 3106 8.0 - 12.0 1000* 20 26/38 45 GRID TNC 2.0/0.9
MEC 3848N 8.0 - 12.0 5,000 8 48/50 32 GRID WR 90 10.0/4.5
MTI 3044C 8.0 - 12.4 1200 4 57/64 12* GRID TNC 6.0/2.7
MTI 3044J 8.0 - 18.0 1,000 4 42/62 12* GRID TNC 6.0/2.7
MTI 3048Q 8.2 - 12.4 3,000* 8 43/50 24* GRID WR 90 6.0/2.7
MTI 3048D 8.7 - 10.5 4,000* 10 45/47 32* GRID WR 90 6.0/2.7
MTI 3948B 8.8 - 10.5 8,000* 5 48/51 35* GRID WR 90 7.5/3.4
MTI 3948 8.8 - 10.5 8,700* 2 50/51 30* GRID WR 90 7.5/3.4
MTI 3948U 9.0 - 10.0 7,945 5 47/48 35 GRID WR 90 9.5/4.3
MEC 3104 12.0 - 18.0 3,470 6 32/39 25 GRID WR 62 9.0/4.1
MTI 3056C 15.0 - 17.0 4,000* 2 50/56 16* GRID WR 62 6.5/3.0
MEC 3116X 15.0 - 18.0 1250 4.5 43/45 20* GRID WR-62 7.0/3.2
MEC 3117X 15.2 - 18.2 400* 35 34/35 32 GRID WR-51 2.0/0.9
MEC 3333 (FWU) 15.5 - 16.5 850 33 46/48 34 GRID WR-51 3.5/1.5
MEC 3086 15.5 - 17.9 700 35 45/48 32 GRID WR 62 9.5/4.3

​*OVER MAJORITY OF FREQUENCY RANGE - PERFORMANCE MAY BE REDUCED AT BAND EDGES.

Specifications Subject To Change Without Notice
Teledyne TWT Products are controlled by the U.S. Government and may require an approved export license. They may not be resold, transferred, or otherwise disposed of, to any other country or to any person other than the authorized ultimate consignee or end-user(s), either in their original form or after being incorporated into other items, without first obtaining approval from the U.S. government or as otherwise authorized by U.S. law and regulations.
