      TMS STANDARD SYNTHESIZERS At-A-Glance
  • SPOTLIGHT: The Advanced Single Loop Frequency Synthesizer (see below)
  • State of the art phase noise performance
  • Tuning speed in nanoseconds
  • Broadband Tuning Range: L to K band
  • SRAs, IMAs, MFM, IFM, LRU
  • Very low SWaP (Size, Weight and Power)
  • DDS in the Loop
Teledyne Microwave Solutions (TMS) has long been a trusted industry supplier of advanced Synthesizers, Converters and Transceivers. TMS's Frequency Synthesizers are available from the very complex dual loop frequency synthesizer to more simple phase locked loop designs, supporting a number of communication bands from L-Band through Ka-Band.

 MARKETS & APPLICATIONS

  • Microwave radio system
  • Satcom converters
  • EW (Electronic Warfare)
  • Test equipment
  • Exciters
  • Jammers
  • Military communication systems

 SPOTLIGHT

The Advanced Single Loop Frequency Synthesizer

Exceptional phase noise performance of <-125dBc/Hz at 100KHz offset over bands covering from 700MHz to 40GHz, with a minimum of 10% bandwidth. Novel design (patent pending) has excellent microphonic performance with no phase hits.

Single board construction with:

  • all surface mount components
  • low cost and repeatable quality
  • low phase noise and superior spurious performance
