PCB Materials

Teledyne Labtech specialise in the manufacture of RF/Microwave PCB utilising PTFE, LCP and high performance ceramic based substrates. These include materials from Rogers, Taconic and Neltec. The materials range in dielectric constant from, 1.96 (RO 5880 LZ) up to 12.85 (TMM 13).

  • All grades of Thermosets and PTFE (1.96 DK - 12.85DK)
  • Matched bond films (FEP & PFA etc.)
  • OhmegaPly® - Planar Resistor Technology
  • Bergquist - Thermal Substrates
  • High Tg multifunctional epoxy
  • Polyimide, Aramid Fibre (Kevlar), Bt Epoxy
  • LCP - Liquid Crystal Polymers



Materials Database

Dk @ 10Ghz range filter:


Dk @ 10GhzMaterialSupplierDf @ 10GhzCTE (ppm/C) X Y ZMoisture Absorption (%)CommentsBondply Material
1.96RT/Duriod 5880 LZRogers0.001941.50.22Filled PTFE Composite
2.17DiClad880-PIMRogers0.000925342520.02Woven Fiberglass reinforced PTFE
2.08NY9208Neltec0.000625352600.02Woven Glass Reinforced PTFE
2.17NY9217Neltec0.000825352600.02Woven Glass Reinforced PTFE
2.17TLY-5ATaconic0.00092020280<0.02PTFE Coated Woven Glass Fabric & PTFE
2.172.2CuClad 217 LXRogers0.000929282460.02Crossplied Woven Fiberglass reinforced PTFE
2.172.2DiClad 880Rogers0.000925342520.02Woven Fiberglass reinforced PTFE
2.172.2Isoclad 917Rogers0.001346472360.04Non-woven Fiberglass reinforced PTFE
2.2NY9220Neltec0.000925352600.02Woven Glass Reinforced PTFE
2.2RT/Duriod 5880Rogers0.00090.02Random Glass Microfiber Reinforced PTFE
2.2TLY-5Taconic0.00092020280<0.02PTFE Coated Woven Glass Fabric & PTFE
2.2TLP-5Taconic0.00092020280<0.02PTFE Coated Woven Glass Fabric & PTFE
2.33CuClad 233 LXRogers0.001323241940.02Crossplied Woven Fiberglass reinforced PTFE
2.33DiClad 870Rogers0.001317292170.02Woven Fiberglass reinforced PTFE
2.33Isoclad 933Rogers0.001631352030.05Non-woven Fiberglass reinforced PTFE
2.33NY9233Neltec0.001125352600.02Woven Glass Reinforced PTFE
2.33RT/Duriod 5870Rogers0.00120.02Random Glass Microfiber Reinforced PTFE
2.33TLY-3Taconic0.00122020280<0.02PTFE Coated Woven Glass Fabric & PTFE
2.4NX9243Neltec0.001612181500.05Woven Glass Reinforced PTFE
2.42.6Ultralam 2000Rogers0.002215152000.03Woven Glass Reinforced PTFE
2.42.6CuClad 250 GTRogers0.001818191770.03Crossplied Woven Fiberglass reinforced PTFE
2.42.6CuClad 250 GXRogers0.001818191770.03Crossplied Woven Fiberglass reinforced PTFE
2.42.6DiClad 522Rogers0.001814211730.03Woven Fiberglass reinforced PTFE
2.42.6DiClad 527Rogers0.001814211730.03Woven PTFE Unidirectional
2.45NX9245Neltec0.001612181500.05Woven Glass Reinforced PTFE
2.45TLX-0Taconic0.0019912145<0.02PTFE / Woven Glass
2.5AD 250Rogers0.00181215950.07Woven Glass & PTFE
2.5AD 250ARogers0.00151215950.04Glass/PTFE Micro-Dispersed Ceramic
2.5NX9250Neltec0.001712181500.05Woven Glass Reinforced PTFE
2.5TLX-9Taconic0.0019912145<0.02PTFE / Woven Glass
2.55AD 255ARogers0.00151616800.04Glass/PTFE Micro-Dispersed Ceramic
2.55AD 255Rogers0.00181215950.07Woven Glass & PTFE
2.55AD 255CRogers0.00141616500.04Glass/PTFE Micro-Dispersed Ceramic
2.55NX9255Neltec0.001812181500.05Woven Glass Reinforced PTFE
2.55TLX-8Taconic0.0019912145<0.02PTFE / Woven Glass
2.6NX9260Neltec0.001912181500.05Woven Glass Reinforced PTFE
2.6TLX-7Taconic0.0019912145<0.02PTFE / Woven Glass
2.6TSM-26Taconic0.00142328780.03PTFE / Woven Glass / Ceramic
2.65TLX-6Taconic0.0019912145<0.02PTFE / Woven Glass
2.65TLA-6Taconic0.00179121400.02PTFE / Woven Glass
2.7AD 270Rogers0.00231215950.07Woven Glass & PTFE
2.7AD 260ARogers0.00171216800.04Glass/PTFE Micro-Dispersed Ceramic
2.7NX9270Neltec0.00212181500.05Woven Glass Reinforced PTFE
2.7Fastfilm 27Taconic0.001229281120.03Non-Reinforced Polymer
2.75TLC-27Taconic0.002291270<0.02PTFE / Woven Glass
2.85TSM-DSTaconic0.0011118570.04PTFE / Woven Glass / Ceramic
2.9Ultralam 3850Rogers0.002517171500.04Liquid Crystal Polymer
2.94CLTE-XTRogers0.001288200.02Glass/PTFE Micro-Dispersed Ceramic
2.94NH9294Neltec0.022912710.08Woven Glass Ceramic Loaded PTFE
2.94NX9294Neltec0.002212181500.05Woven Glass Reinforced PTFE
2.94RT/Duroid 6002Rogers0.00121616240.1Ceramic/PTFE Blend
2.94RT/Duroid 6202Rogers0.00151515300.1Ceramic/PTFE Woven
2.94TSM-29Taconic0.00132328780.03PTFE / Woven Glass / Ceramic
2.95TLE-95Taconic0.002691270<0.02PTFE / Woven Glass
2.97AD 300CRogers0.0021212500.05Glass/PTFE Micro-Dispersed Ceramic
2.98CLTERogers0.00251012340.04Glass/PTFE Micro-Dispersed Ceramic
3CLTE-ATRogers0.01388200.03Glass/PTFE Micro-Dispersed Ceramic
3AD 300ARogers0.00312121250.02Glass/PTFE Micro-Dispersed Ceramic
3NH9300Neltec0.0023912710.08Woven Glass Ceramic Loaded PTFE
3NX9300Neltec0.002312181500.05Woven Glass Reinforced PTFE
3N9300-13RFNeltec0.0041320670.07Blended PTFE/Epoxy
3RO3003Rogers0.0013171724<0.10Ceramic filled PTFE Composite
3RO4730Rogers0.00331917400.13Thermoset Closed Microsphere Filler
3TLC-30Taconic0.002891270<0.02PTFE / Woven Glass
3TSM-30Taconic0.00132328780.03PTFE / Woven Glass / Ceramic
3RF-30Taconic0.001411212080.02PTFE / Woven Glass / Ceramic
3.02RO3203Rogers0.0016131358<0.10Ceramic filled PTFE & Woven Glass
3.2AD 320ARogers0.003214141280.02Glass/PTFE Micro-Dispersed Ceramic
3.2AD 320Rogers0.00381215950.06Glass/PTFE Micro-Dispersed Ceramic
3.2NH 9320Neltec0.0024912710.08Woven Glass Ceramic Loaded PTFE
3.2NX9320Neltec0.002412181500.05Woven Glass Reinforced PTFE
3.2N9320-13RFNeltec0.00451320670.07Blended PTFE/Epoxy
3.2N8000QNeltec0.0061113700.05Cyanate Ester Epoxy
3.2TLC-32Taconic0.00391270<0.02PTFE / Woven Glass
3.23XT/Duroid 8000Rogers0.00351823680.2Non PTFE Thermoplastic
3.27TMM 3Rogers0.0021515230.06Ceramic Thermoset Polymer Composite
3.3RO4533Rogers0.0025131137Glass Reinforced Hydrocarbon Ceramic Laminate
3.3825NRogers0.00251515520.09Ceramic Hydrocarbon
3.38NH 9338Neltec0.0025912710.08Woven Glass Ceramic Loaded PTFE
3.38N9338-13RFNeltec0.00461320670.07Blended PTFE/Epoxy
3.38RO4003CRogers0.00271114460.06Glass Reinforced Hydrocarbon Ceramic Laminate
3.4RO4534Rogers0.0027111446Glass Reinforced Hydrocarbon Ceramic Laminate
3.4Syron 7000Rogers0.00451823680.2Thermoplastic
3.4TLF-34Taconic0.0022123850.02PTFE / Glass
3.48NH 9348Neltec0.003912710.08Woven Glass Ceramic Loaded PTFE
3.48RO4350BRogers0.00371416350.06Glass Reinforced Hydrocarbon Ceramic Laminate
3.5AD 350ARogers0.00359350.1Glass/PTFE Micro-Dispersed Ceramic
3.5TC 250Rogers0.00277230.05Glass/PTFE Micro-Dispersed Ceramic
3.5NH 9350Neltec0.003912710.08Woven Glass Ceramic Loaded PTFE
3.5N9350-13RFNeltec0.00551320670.07Blended PTFE/Epoxy
3.5N8000Neltec0.0111113700.05Cyanate Ester Epoxy
3.5N4350-13RF 6Neltec0.006514143.50%0.1Modified Epoxy
3.5Mercurywave 9350Neltec0.041014480.15Non PTFE
3.5RO3035Rogers0.0018171724<0.1Ceramic filled PTFE Composite
3.5RO4535Rogers0.0037141635Glass Reinforced Hydrocarbon Ceramic Laminate
3.5RF-35Taconic0.00181924640.02PTFE / Woven Glass / Ceramic
3.5RF-35A2Taconic0.00158101040.02PTFE / Woven Glass / Ceramic
3.5RF-35PTaconic0.003415151100.03PTFE / Woven Glass / Ceramic
3.5TLF-35Taconic0.0022123850.02PTFE / Glass
3.5825FRRogers0.00351618590.09Ceramic Hydrocarbon
3.8N4380-13RF 6Neltec0.00814143.50%0.1Modified Epoxy
4.1AD 410Rogers0.00399400.06Glass/PTFE Micro-Dispersed Ceramic
4.1NH9410Neltec0.003912710.08Woven Glass Ceramic Loaded PTFE
4.3AD 430Rogers0.00399400.06Glass/PTFE Micro-Dispersed Ceramic
4.5AD 450Rogers0.0035811420.07Glass/PTFE Micro-Dispersed Ceramic
4.5NH9450Neltec0.003912710.08Woven Glass Ceramic Loaded PTFE
4.5TMM 4Rogers0.0021616210.07Ceramic Thermoset Polymer Composite
4.5AD 450A 3Rogers0.0031010400.06Glass/PTFE Micro-Dispersed Ceramic
6TMM 6Rogers0.00231818260.06Ceramic Thermoset Polymer Composite
6.15AD 600Rogers0.0031110450.04Glass/PTFE Micro-Dispersed Ceramic
6.15TC 600Rogers0.00299350.03Glass/PTFE Micro-Dispersed Ceramic
6.15RO3006Rogers0.002171724<0.10Ceramic filled PTFE Composite
6.15RO3206Rogers0.0027131334<0.10Ceramic filled PTFE & Woven Glass
6.15RT/Duroid 6006Rogers0.002747341170.05Ceramic filled PTFE Composite
6.15RO4360Rogers0.003817105300.13Glass Reinforced Ceramic Filled Thermoset
6.15RF-60ATaconic0.00389869<0.02PTFE / Woven Glass / Ceramic
7.6R02808Rogers0.00153030230.03Composite Fluropolymer
9.2TMM 10Rogers0.00222121200.09Ceramic Thermoset Polymer Composite
9.8TMM 10iRogers0.0021919200.16Ceramic Thermoset Polymer Composite
10AR 1000Rogers0.0031416370.08Glass/PTFE Micro-Dispersed Ceramic
10AD 1000Rogers0.0023810200.03Glass/PTFE Micro-Dispersed Ceramic
10CER-10Taconic0.00351315460.02PTFE / Woven Glass / Ceramic
10.2RO3210Rogers0.0027131334<0.10Ceramic filled PTFE & Woven Glass
10.2RO3010Rogers0.0023171724<0.10Ceramic filled PTFE Composite
10.2RT/Duroid 6010.2LMRogers0.00232424470.05Ceramic filled PTFE Composite
2FEP-ADu-Pont0.0007XXX<0.01PTFE Thermoplastic Filmy
2PFADu-Pont0.0007XXX<0.01PTFE Thermoplastic Filmy
2.28RO3001Rogers0.003XXX0.05Thermoplastic Chloro-Fluorocopolymery
2.32CuClad 6250Rogers0.0013XXX<0.01Bond Filmy
2.35TacBond HT 1.5Taconic0.0025XXX<0.01Thermoplastic Filmy
2.35CuClad 6700Arlon0.0025XXX<0.01Bond Filmy
2.7Fastrise 27Taconic0.00145970720.08Thermoset Prepregy
2.9Ultralam 3908Rogers0.0021717X0.04Liquid Crystal Polymery
2.94CLTE-PRogers0.00251012350.04Ceramic Filled PTFE Glassy
2.96Fastrise DSTaconic0.00181117660.1Thermoset Prepregy
3TPG 30Taconic0.003821231080.13Thermoset Prepregy
3.17RO4403Rogers0.0051619800.05Glass Reinforced Hydrocarbon/Ceramicy
3.3RO4450B 5Rogers0.0041917600.1Glass Reinforced Hydrocarbon/Ceramicy
3.5TPG 35Taconic0.00521231080.13Thermoset Prepregy
3.54RO4450FRogers0.0041917500.09Glass Reinforced Hydrocarbon/Ceramicy
3.54RO4450B 4Rogers0.0041917500.05Glass Reinforced Hydrocarbon/Ceramicy
7.7Fastrise 77Taconic0.00341017620.1Thermoset Prepregy

Electrically / Thermally Conductive Adhesive

T Cond
W/m K
MaterialSupplierVol Resis
ohm-cm
CTE (ppm/oC)
X Y Z
Moisture
Absorption (%)
Comments
1.60Ablefilm ECF 561ELoctite0.0060656565XSilver filled epoxy adhesive
> 3.00Staystik 581Cookson0.0005   XSilver filled Thermoplastic
6.50Ablefilm 5025ELoctite0.0002100100100XSilver filled epoxy adhesive
7.00CF 3350Loctite0.00026565650.50Silver filled epoxy adhesive
 Staystik 8000Cookson0.00056767670.50Silver filled Thermoplastic/Thermoset Hybrid
